In the combustion process, the pistons convert energy into mechanical work. The most preferred material used for manufacturing is aluminum. The main reasons for using aluminum are due to low density, higher reliability, higher thermal conductivity, and better recycling ability. The two methods of manufacturing pistons are mainly casting and forging. Cast piston manufacturing is cheaper due to its simpler method. It is also one of the most commonly used manufacturing processes. However, the forging method of piston pin and piston is a more complicated process in manufacturing, using a solid aluminum alloy. This blog tells you about the manufacturing process of this amazingly durable engine component called the piston.
The first piece of a piston begins with the making of an aluminum rod. There are many advantages of using aluminum in the process of the making of the rod. Aluminium is light in weight, rust-proof and easy to cut. Though the rod is very long in legnth, a saw cuts it into smaller pieces at various lengths. The slugs have the small pieces of this rod.
When the slug passes through the oven the punch press becomes hotter. Slugs pass through the oven at the same temperature of a punch press. Once the slug is removed from the oven, it is put in the punch. The press exerts almost 2000 tons of pressure in forming the slug into a defined piston shape. The piston is kept cool in the air for about an hour.
The slugs cool down, after which they pass twice through the oven. It passes through the oven to strengthen the metal. The first time is hot. Then, it is passed through a lower temperature to stabilize it.
Then, the lathe cuts out the basic shape of the piston. It helps to give the piston the last shape. Piston is create with little holes on the sides so that oil can pass through. The lathe pushes three rings into the top of the piston.
Apart from the three tiny holes, one big hole is necessary to enter the piston pin. The large hole is drilled on both sides of the piston. It facilitates attachment of piston to the rod during piston assembly procedure.
After boring the wrist pin, a milling machine shaves up a few centimeters from all sides of the piston. Shaving occurs when a large bore hole is drilled to go inside the wrist pin. That shaving away of metal lightens the weight of the piston. A milling machine shaves the metal from the sides of the piston near to the area of three rings to give piston its the final shape.
In the final stage, the lathe removes a few more millimeters from the top. It makes room for the piston to expand if heat forms inside it. Sharp edges will smooth out. Later on, a machine smoothes the holes in which the wrist pins are placed. This will let the wrist pin fit.
Piston quality has to be maintained. The presence of these materials indicates the compliance with some standard standards. The aluminium alloys are classified into particular categories. Even, it comprises different compositions. These structures are Si, Cu, Mg, Fe, Mn, Ni, Zn etc. There is a specific hardness between 90 to 140 HB. Tensile strength must lie between 165 to 275 Nmm2 for the different categories.
With climate change concerns opting for sustainable manufacturing should be top of the agenda. You should opt for an environment-friendly piston ring manufacturing method. You should minimize the pollution in the process of manufacturing. You should obtain permission from the State Pollution Control Board before starting up the manufacturing process.
You need to study the piston market. It needs to be optimum. For instance, India would definitely offer a good piston market as the automobile industry is growing in the country. The growth rate of automobile sales is expected at 10-15%. Hence, the market of pistons in India is huge. You can compare the growth rate of the piston sales before producing them. It will also enable you to estimate the success rate of the probability for you in this market.
There are numerous choices while manufacturing pistons, in raw materials selection. You should also decide that which material is more likely to be in demands in the market. Also, the product where the pistons will be used. Aluminium alloys are used while making pistons targeting on gasoline and diesel engines. As aluminium alloys have some special qualities like low density, high thermal conductivity, and strong consistency.
After finalizing which materials you will be using for the making of the piston, you should also have in your knowledge the proper ratio of those materials. You should well know the ratios of the material and the heat. The structure and heat should be perfect to get the right result.
Piston and piston pin design plays an extremely important role in an efficient engine that has a healthy, long life. A good piston needs to be strong, lightweight, and able to resist thermal expansion under high-pressure, high-temperature environments. In the same manner, piston pins should withstand the force built up during the passage of forces from the piston to the connecting rod, with proper choice of materials, fit, and lubrication for decreased wear. The piston and the pin together .
